Sika SikaTile-110 Secure Proof Membrane

Description

Sika SikaTile-110 Secure Proof Membrane
– 15 Litre Bucket



Sika SikaTile-110 Secure Proof is a rapid drying, water-based class III flexible
waterproofing membrane designed for wet areas, balconies and other under tile and
stone waterproofing applications.



Description

• SikaTile®-110 Secure Proof is a suitable undertile waterproofing membrane that complies to AS/NZS 4654:2012 and AS 4858:2004.



Uses

SikaTile®-110 Secure Proof is suitable for use on walls and floors for both internal and external applications.
SikaTile®-110 Secure Proof is suitable for most typical construction substrates such as;

• Concrete
• GRC – Glass reinforced concrete
• Cement boards and sheets including
• Scyon
• Renders and screeds
• Cement coated light weight construction boards
• Plasterboard
• Structural Plywood
• Autoclaved Aerated Concrete (AAC)



Features

• Premixed, ready to use
• UV Stable – Exposed rooftops & balconies under pedestal and paver
• High extensibility, Class III
• High elongation ≤500%
• Class III flexible performance
• Solvent free, water-based
• Fibre reinforced
• Excellent antifracture properties
• Excellent cure time
• Low VOC



Packaging

• 15 Litre Pails/32Pails per Pallet



Shelf Life

• 12 months from date of manufacture when stored unopened in an elevated, cool, dry location



Storage Conditions

• Store in dry cool conditions, out of direct sunlight.
• Do not allow membrane to freeze



Appearance and Colour

• Grey



VOC Content

• Low VOC – 62g/l ASTM-D3960-05



Consumption

• The minimum dry film thickness required is 1.0mm applied in a minimum
  of 2 coats.
• SikaTile®-110 Secure Proof shall be applied to the substrate at a rate
  of 0.75mm wet film thickness per coat.
• A 15Ltr pail will cover approximately 10m2.
• The minimum dry film thickness for Pedestall and Paver application is
  1.62mm.



Ambient Air Temperature

• >5ºC – <35ºC



Wait Times

Waiting times anssume an ambient air temperature of 23º and 50% relative Humidity.
Specified times act as a guide only and will vary according to conditions.

• Waiting time to application of the second coat – 1 to 2 hours
• Waiting time prior to tiling – 6 to 8 hours after final coat
• ready for Flood Testing – 48 hours
• Return to service – 3+ days

NOTE: All measurements are taken at 23ºC and 50% relative humidity. Specifications vary according to site conditions and should be taken as a guide only.



Limitations of Use

• SikaTile®-110 Secure Proof is not suitable for applications in areas of permanent water immersion.
• SikaTile®-110 Secure Proof is not suitable for applications in area of negative hydrostatic pressure or rising damp.
• Delay applications if rain or inclement weather is imminent.
• SikaTile®-110 Secure Proof must be applied at the recommended coverage rates.
• Tongue & groove timber flooring must be oversheeted with fibre cement sheeting or ceramic tile underlay.
• Particle board flooring shall be adequately prepared with all contaminates removed.
• To minimise the chance of damage install finished covering as soon as possible once the membrane has cured.
• SikaTile®-110 Secure Proof must not be used as a wearing surface for foot and vehicular traffic.
• Contact Sika® for information or applications not mentioned in the document.



Priming

• General Priming
  SikaTile® 010 Secure Prime
• Green Screeds or Renders
  Sikalastic Moisture Seal
• Existing Tiles
  SikaTile® 010 Secure Prime
• Autoclaved Aerated Concrete
  Sika Prep n Prime

NOTE: Refer to the specific primer product data sheet for complete instructions.



Mixing

• Stir the membrane with a paddle prior to use.



Application

• Apply the SikaTile®-110 Secure Proof to substrate with a medium nap roller allowing to dry between coats.
• Under tile applications shall be applied in a minimum of 2 coats to acheive a minimum dry film thickness of 1.0mm.
• Under pedestall and paver application shall be applied in a mnimum 3+ coats to achesive a minimum dry film thickness of 1.62mm.

Please Note:

• Pedestal and paver application, membrane should be periodically checked to ensure pedestalls remain i place and not dislodged, or damaging the membrane.
• Alternatively protective pads or a protection mat can be placed under the pedestals as a means



Cleaning of Equipment

• Clean all tools and application equipment immediately
  after use with water. Once cured, residual material can
  only be removed mechanically.
